Red Dot Award 2024 Winning Design
Carefully sculpted rounded edges, soft contact materials, and soothing lighting alleviate patient distress during mammography exams.
Premium Full-Field Digital Mammography (FFDM)
DRTECH AIDIA VOLVE Full-Field Digital Mammography
Red Dot 2024 Award-Winning Ergonomic Digital Mammography Platform
The DRTECH AIDIA VOLVE is a premium full-field digital mammography (FFDM) system recognized with the prestigious Red Dot Design Award 2024. Featuring an ultra-fine 65 µm direct-conversion a-Se detector (or 76 µm CsI option), Tungsten target tube with Rh/Ag switching filtration, smart 1-2-3 paddle decompression, and the RConsole 2 workstation powered by TRUVIEW® M2 post-processing, AIDIA VOLVE delivers unmatched diagnostic confidence and a soothing, patient-friendly examination experience.
- System Modality
- Full-Field Digital Mammography (FFDM) with Tomosynthesis Readiness
- Detector Technology
- Direct-conversion Amorphous Selenium (a-Se) or High-sensitivity CsI:Tl
- Pixel Pitch
- 65 µm (a-Se Direct) / 76 µm (CsI Indirect)
DRTECH Corporation / Mammography Systems
DRTECH AIDIA VOLVE Full-Field Digital Mammography
Mammography Systems
DRTECH AIDIA VOLVE Full-Field Digital Mammography
DRTECH Corporation
DRTECH AIDIA VOLVE Full-Field Digital Mammography
Mammography Systems
Product overview
Red Dot 2024 Award-Winning Ergonomic Digital Mammography Platform
The DRTECH AIDIA VOLVE is a premium full-field digital mammography (FFDM) system recognized with the prestigious Red Dot Design Award 2024. Featuring an ultra-fine 65 µm direct-conversion a-Se detector (or 76 µm CsI option), Tungsten target tube with Rh/Ag switching filtration, smart 1-2-3 paddle decompression, and the RConsole 2 workstation powered by TRUVIEW® M2 post-processing, AIDIA VOLVE delivers unmatched diagnostic confidence and a soothing, patient-friendly examination experience.
01Red Dot Award 2024 Winning Design
0265 µm Direct-Conversion a-Se Detector
03TRUVIEW® M2 MTF Enhancement
04Intelligent Smart AEC Dose Control
051-2-3 Smart Paddle Decompression
06Integrated Gantry Footprint
Core specifications
- System Modality
- Full-Field Digital Mammography (FFDM) with Tomosynthesis Readiness
- Detector Technology
- Direct-conversion Amorphous Selenium (a-Se) or High-sensitivity CsI:Tl
- Pixel Pitch
- 65 µm (a-Se Direct) / 76 µm (CsI Indirect)
- X-ray Tube
- Tungsten (W) Anode high-output tube
- Filtration System
- Switching Dual Filter (Rhodium / Silver - Rh/Ag)
- Focal Spot Size
- 0.1 mm (Small) / 0.3 mm (Large)
- Dose Management
- Multi-point intelligent AEC with automatic thickness and density tracking
- Compression System
- Soft-touch motorized compression with "1-2-3" automatic quick decompression
- Gantry Footprint
- Internalized high-voltage generator design for compact room installation
- Acquisition Workstation
- RConsole 2 dedicated workstation with TRUVIEW® M2 post-processing
- PACS Connectivity
- Full DICOM 3.0 compliance (Storage, Worklist, Query/Retrieve, MPPS)
- Awards & Accreditations
- Red Dot Design Award Winner 2024, CE, ISO 13485, KFDA
Experience optimized workflow
High resolution cassette-sized digital imaging
The DRTECH AIDIA VOLVE is a premium full-field digital mammography (FFDM) system recognized with the prestigious Red Dot Design Award 2024. Featuring an ultra-fine 65 µm direct-conversion a-Se detector (or 76 µm CsI option), Tungsten target tube with Rh/Ag switching filtration, smart 1-2-3 paddle decompression, and the RConsole 2 workstation powered by TRUVIEW® M2 post-processing, AIDIA VOLVE delivers unmatched diagnostic confidence and a soothing, patient-friendly examination experience.
Designed per ISO 4090 standard to fit standard Bucky trays with 139µm pixel pitch and 16-bit ADC for exceptional diagnostic detail.
01
Red Dot Award 2024 Winning Design
02
65 µm Direct-Conversion a-Se Detector
03
TRUVIEW® M2 MTF Enhancement
04
Intelligent Smart AEC Dose Control
05
1-2-3 Smart Paddle Decompression
06
Integrated Gantry Footprint
Key features
Designed around the way you work
Each capability is integrated to improve everyday operation, examination consistency, and confidence at the point of care.
65 µm Direct-Conversion a-Se Detector
Class-leading 65 µm pixel size captures micro-calcification clusters with needle-sharp acuity and zero light-scattering blur.
TRUVIEW® M2 MTF Enhancement
Patented algorithmic processing reconstructs edge fidelity and MTF across both low-density fatty and dense glandular tissue regions.
Intelligent Smart AEC Dose Control
Continuously measures breast thickness and glandular density to deliver tailored, optimized low-dose exposure curves.
1-2-3 Smart Paddle Decompression
Instantaneous, controlled paddle release upon exposure conclusion minimizes uncomfortable compression duration.
Integrated Gantry Footprint
High-voltage generator is internalized directly within the gantry frame, saving valuable exam room floor space.
Performance and workflow
Built for reliable daily operation.
DRTECH AIDIA VOLVE Full-Field Digital Mammography brings its core functions together in one coherent workflow, helping operators position, acquire, review, and complete examinations with fewer unnecessary steps.
01
System Modality
Full-Field Digital Mammography (FFDM) with Tomosynthesis Readiness
02
Detector Technology
Direct-conversion Amorphous Selenium (a-Se) or High-sensitivity CsI:Tl
03
Pixel Pitch
65 µm (a-Se Direct) / 76 µm (CsI Indirect)
Clinical focus
Red Dot 2024 Award-Winning Ergonomic Digital Mammography Platform
Red Dot 2024 Award-Winning Ergonomic Digital Mammography Platform
System information
Product details and resources
Review core configuration details, workflow information, and available product resources.
- System Modality
- Full-Field Digital Mammography (FFDM) with Tomosynthesis Readiness
- Detector Technology
- Direct-conversion Amorphous Selenium (a-Se) or High-sensitivity CsI:Tl
- Pixel Pitch
- 65 µm (a-Se Direct) / 76 µm (CsI Indirect)
- X-ray Tube
- Tungsten (W) Anode high-output tube
- Filtration System
- Switching Dual Filter (Rhodium / Silver - Rh/Ag)
- Focal Spot Size
- 0.1 mm (Small) / 0.3 mm (Large)
- Dose Management
- Multi-point intelligent AEC with automatic thickness and density tracking
- Compression System
- Soft-touch motorized compression with "1-2-3" automatic quick decompression
- Gantry Footprint
- Internalized high-voltage generator design for compact room installation
- Acquisition Workstation
- RConsole 2 dedicated workstation with TRUVIEW® M2 post-processing
- PACS Connectivity
- Full DICOM 3.0 compliance (Storage, Worklist, Query/Retrieve, MPPS)
- Awards & Accreditations
- Red Dot Design Award Winner 2024, CE, ISO 13485, KFDA
Designed for daily confidence
DRTECH AIDIA VOLVE Full-Field Digital Mammography combines accessible controls, optimized positioning, and high image quality to keep examinations moving smoothly.
- Red Dot Award 2024 Winning Design
- 65 µm Direct-Conversion a-Se Detector
- TRUVIEW® M2 MTF Enhancement
- Intelligent Smart AEC Dose Control
- 1-2-3 Smart Paddle Decompression
- Integrated Gantry Footprint
Product resources
Detailed brochures, configuration guidance, and regulatory documents are available from TMS Enterprise.
