Dual Cassette Format Support
Accepts both 18×24 cm and 24×30 cm film cassettes, providing versatility for various patient breast sizes and screening requirements.
Analog Film-Screen Mammography System
Navigator Platinum Mammography
Affordable High-Precision Mammography with CR Upgradeability
The Navigator Platinum is an analog film-screen mammography system supporting both 18×24 cm and 24×30 cm cassettes. Built with a high-end dual-focus IAE X-ray tube featuring Mo/W target, 100 kHz high-frequency generator, iso-centric C-arm rotation (+180° to -135°), and intelligent multilevel compression, it delivers exceptional diagnostic image quality at minimal radiation doses. An ideal choice for hospitals and clinics seeking dependable performance with straightforward upgradeability to CR digital mammography.
- System Type
- Analog Film-Screen Mammography (CR Ready)
- Film / Cassette Sizes
- 18 × 24 cm and 24 × 30 cm
- X-ray Generator
- 100 kHz High Frequency, 5 kW
Sinomdt (Sino Medical-Device Technology Co., Ltd.) / Mammography Systems
Navigator Platinum Mammography
Mammography Systems
Navigator Platinum Mammography
Sinomdt (Sino Medical-Device Technology Co., Ltd.)
Navigator Platinum Mammography
Mammography Systems
Product overview
Affordable High-Precision Mammography with CR Upgradeability
The Navigator Platinum is an analog film-screen mammography system supporting both 18×24 cm and 24×30 cm cassettes. Built with a high-end dual-focus IAE X-ray tube featuring Mo/W target, 100 kHz high-frequency generator, iso-centric C-arm rotation (+180° to -135°), and intelligent multilevel compression, it delivers exceptional diagnostic image quality at minimal radiation doses. An ideal choice for hospitals and clinics seeking dependable performance with straightforward upgradeability to CR digital mammography.
01Dual Cassette Format Support
02High-End IAE Dual-Focus Tube
03Iso-Centric C-Arm Rotation
04Intelligent Multilevel Compression
05Seamless CR Digital Upgrade
06Integrated High-Frequency Generator
Core specifications
- System Type
- Analog Film-Screen Mammography (CR Ready)
- Film / Cassette Sizes
- 18 × 24 cm and 24 × 30 cm
- X-ray Generator
- 100 kHz High Frequency, 5 kW
- Tube Voltage Range
- 20 kV to 40 kV (1 kV step adjustments)
- Tube Current Range
- 15 mA to 110 mA
- X-ray Tube
- Italian IAE dual-focus with Molybdenum/Tungsten (Mo/W) target
- Focal Spot Size
- 0.1 mm (Fine / Small) / 0.3 mm (Broad / Large)
- C-Arm Rotation
- Iso-centric motorized rotation (+180° / -135°)
- Source-to-Image Distance (SID)
- 650 mm
- Exposure Modes
- Manual, Automatic (AEC), Full Automatic (AAEC)
- Compression Modes
- Motorized multilevel flexible compression with manual fine-tune
- Control Panel
- Dual-side touchscreen controls and foot-switch activation
- Power Supply
- 220V / 230V AC ± 10%, 50/60 Hz
- Certifications
- CE (TUV Rheinland), ISO 13485, ISO 9001
Experience optimized workflow
High resolution cassette-sized digital imaging
The Navigator Platinum is an analog film-screen mammography system supporting both 18×24 cm and 24×30 cm cassettes. Built with a high-end dual-focus IAE X-ray tube featuring Mo/W target, 100 kHz high-frequency generator, iso-centric C-arm rotation (+180° to -135°), and intelligent multilevel compression, it delivers exceptional diagnostic image quality at minimal radiation doses. An ideal choice for hospitals and clinics seeking dependable performance with straightforward upgradeability to CR digital mammography.
Designed per ISO 4090 standard to fit standard Bucky trays with 139µm pixel pitch and 16-bit ADC for exceptional diagnostic detail.
01
Dual Cassette Format Support
02
High-End IAE Dual-Focus Tube
03
Iso-Centric C-Arm Rotation
04
Intelligent Multilevel Compression
05
Seamless CR Digital Upgrade
06
Integrated High-Frequency Generator
Key features
Designed around the way you work
Each capability is integrated to improve everyday operation, examination consistency, and confidence at the point of care.
High-End IAE Dual-Focus Tube
Equipped with an Italian IAE X-ray tube featuring Molybdenum (Mo) and Tungsten (W) target with 0.1mm / 0.3mm focal spots for micro-calcification clarity.
Iso-Centric C-Arm Rotation
Patented iso-center C-arm rotates smoothly from +180° to -135°, maintaining height alignment to save exam time during CC, MLO, and lateral projections.
Intelligent Multilevel Compression
Motorized compression paddle with multi-stage pressure sensing minimizes patient discomfort while providing uniform tissue thickness for sharper imaging.
Seamless CR Digital Upgrade
Compatible with computed radiography (CR) imaging plates (IP boards), enabling easy transition to digital workflow without hardware replacement.
Integrated High-Frequency Generator
100 kHz high-frequency standalone generator guarantees stable radiation output and minimizes patient exposure with advanced AEC.
Performance and workflow
Built for reliable daily operation.
Navigator Platinum Mammography brings its core functions together in one coherent workflow, helping operators position, acquire, review, and complete examinations with fewer unnecessary steps.
01
System Type
Analog Film-Screen Mammography (CR Ready)
02
Film / Cassette Sizes
18 × 24 cm and 24 × 30 cm
03
X-ray Generator
100 kHz High Frequency, 5 kW
Clinical focus
Affordable High-Precision Mammography with CR Upgradeability
Affordable High-Precision Mammography with CR Upgradeability
System information
Product details and resources
Review core configuration details, workflow information, and available product resources.
- System Type
- Analog Film-Screen Mammography (CR Ready)
- Film / Cassette Sizes
- 18 × 24 cm and 24 × 30 cm
- X-ray Generator
- 100 kHz High Frequency, 5 kW
- Tube Voltage Range
- 20 kV to 40 kV (1 kV step adjustments)
- Tube Current Range
- 15 mA to 110 mA
- X-ray Tube
- Italian IAE dual-focus with Molybdenum/Tungsten (Mo/W) target
- Focal Spot Size
- 0.1 mm (Fine / Small) / 0.3 mm (Broad / Large)
- C-Arm Rotation
- Iso-centric motorized rotation (+180° / -135°)
- Source-to-Image Distance (SID)
- 650 mm
- Exposure Modes
- Manual, Automatic (AEC), Full Automatic (AAEC)
- Compression Modes
- Motorized multilevel flexible compression with manual fine-tune
- Control Panel
- Dual-side touchscreen controls and foot-switch activation
- Power Supply
- 220V / 230V AC ± 10%, 50/60 Hz
- Certifications
- CE (TUV Rheinland), ISO 13485, ISO 9001
Designed for daily confidence
Navigator Platinum Mammography combines accessible controls, optimized positioning, and high image quality to keep examinations moving smoothly.
- Dual Cassette Format Support
- High-End IAE Dual-Focus Tube
- Iso-Centric C-Arm Rotation
- Intelligent Multilevel Compression
- Seamless CR Digital Upgrade
- Integrated High-Frequency Generator
Product resources
Detailed brochures, configuration guidance, and regulatory documents are available from TMS Enterprise.
