3D Digital Breast Tomosynthesis (DBT)
Multi-angle tomographic sweep reconstructs 1 mm tissue slices to uncover hidden lesions within dense fibroglandular tissue.
3D Tomosynthesis Digital Mammography System
Navigator Star Series Digital Mammography (3000A)
Next-Generation 3D Digital Breast Tomosynthesis & Dual-Energy Imaging
The Navigator Star Series (Navigator 3000A) represents Sinomdt’s flagship 3D Digital Breast Tomosynthesis (DBT) platform. Engineered with a large 24×30 cm flat-panel detector, high-speed Tungsten anode X-ray tube, and pseudo-color micro-calcification algorithms, it supports 2D, 3D tomosynthesis, and 2D+3D combo exposure modes. By resolving overlapping tissue structures, it dramatically increases diagnostic sensitivity while reducing recall rates.
- System Modality
- 2D Full-Field Digital Mammography & 3D Digital Breast Tomosynthesis (DBT)
- Detector Type
- High-speed Amorphous Silicon (a-Si) FPD
- Active Detector Area
- 24 × 30 cm
Sinomdt (Sino Medical-Device Technology Co., Ltd.) / Mammography Systems
Navigator Star Series Digital Mammography (3000A)
Mammography Systems
Navigator Star Series Digital Mammography (3000A)
Sinomdt (Sino Medical-Device Technology Co., Ltd.)
Navigator Star Series Digital Mammography (3000A)
Mammography Systems
Product overview
Next-Generation 3D Digital Breast Tomosynthesis & Dual-Energy Imaging
The Navigator Star Series (Navigator 3000A) represents Sinomdt’s flagship 3D Digital Breast Tomosynthesis (DBT) platform. Engineered with a large 24×30 cm flat-panel detector, high-speed Tungsten anode X-ray tube, and pseudo-color micro-calcification algorithms, it supports 2D, 3D tomosynthesis, and 2D+3D combo exposure modes. By resolving overlapping tissue structures, it dramatically increases diagnostic sensitivity while reducing recall rates.
013D Digital Breast Tomosynthesis (DBT)
02Flexible Combo Exposure Modes
03High-Resolution 24×30 cm FPD
04High-Speed Tungsten (W) Anode Tube
05Pseudo-Color Micro-Calcification Enhancement
06Streamlined Dual-Touchscreen Gantry
Core specifications
- System Modality
- 2D Full-Field Digital Mammography & 3D Digital Breast Tomosynthesis (DBT)
- Detector Type
- High-speed Amorphous Silicon (a-Si) FPD
- Active Detector Area
- 24 × 30 cm
- Spatial Resolution
- 6.0 Lp/mm
- X-ray Tube Anode
- Tungsten (W) Target with high thermal capacity
- Focal Spot Size
- 0.1 mm / 0.3 mm dual-focus
- Tube Voltage Range
- 20 kV to 40 kV in 1 kV increments
- Exposure Modes
- 2D Mode, 3D Tomo Mode, 2D+3D Combo Mode
- C-Arm Rotation
- ±180° iso-centric motorized rotation
- Breast Support Height
- 650 mm – 1350 mm motorized travel range
- Image Processing
- TRUVIEW image reconstruction, pseudo-color micro-calcification enhancement
- Connectivity
- Full DICOM 3.0 (Storage, Worklist, Print, Query/Retrieve)
- Net Weight
- 300 kg (Gantry)
- Certifications
- ISO 9001, ISO 13485, CE
Experience optimized workflow
High resolution cassette-sized digital imaging
The Navigator Star Series (Navigator 3000A) represents Sinomdt’s flagship 3D Digital Breast Tomosynthesis (DBT) platform. Engineered with a large 24×30 cm flat-panel detector, high-speed Tungsten anode X-ray tube, and pseudo-color micro-calcification algorithms, it supports 2D, 3D tomosynthesis, and 2D+3D combo exposure modes. By resolving overlapping tissue structures, it dramatically increases diagnostic sensitivity while reducing recall rates.
Designed per ISO 4090 standard to fit standard Bucky trays with 139µm pixel pitch and 16-bit ADC for exceptional diagnostic detail.
01
3D Digital Breast Tomosynthesis (DBT)
02
Flexible Combo Exposure Modes
03
High-Resolution 24×30 cm FPD
04
High-Speed Tungsten (W) Anode Tube
05
Pseudo-Color Micro-Calcification Enhancement
06
Streamlined Dual-Touchscreen Gantry
Key features
Designed around the way you work
Each capability is integrated to improve everyday operation, examination consistency, and confidence at the point of care.
Flexible Combo Exposure Modes
Supports 2D imaging, 3D tomosynthesis, and simultaneous 2D+3D Combo modes within a single compression cycle.
High-Resolution 24×30 cm FPD
Delivers exceptional spatial resolution of 6 Lp/mm for crystal-clear depiction of subtle micro-calcifications.
High-Speed Tungsten (W) Anode Tube
Equipped with a high-heat-capacity Tungsten anode tube with 0.1/0.3 mm focal spots, optimizing penetration while minimizing dose.
Pseudo-Color Micro-Calcification Enhancement
Proprietary image processing algorithms highlight calcification clusters with distinctive color mapping for faster diagnosis.
Streamlined Dual-Touchscreen Gantry
Ergonomic dual-sided touchscreen display consoles allow clinicians to monitor and adjust all exposure parameters at the gantry.
Performance and workflow
Built for reliable daily operation.
Navigator Star Series Digital Mammography (3000A) brings its core functions together in one coherent workflow, helping operators position, acquire, review, and complete examinations with fewer unnecessary steps.
01
System Modality
2D Full-Field Digital Mammography & 3D Digital Breast Tomosynthesis (DBT)
02
Detector Type
High-speed Amorphous Silicon (a-Si) FPD
03
Active Detector Area
24 × 30 cm
Clinical focus
Next-Generation 3D Digital Breast Tomosynthesis & Dual-Energy Imaging
Next-Generation 3D Digital Breast Tomosynthesis & Dual-Energy Imaging
System information
Product details and resources
Review core configuration details, workflow information, and available product resources.
- System Modality
- 2D Full-Field Digital Mammography & 3D Digital Breast Tomosynthesis (DBT)
- Detector Type
- High-speed Amorphous Silicon (a-Si) FPD
- Active Detector Area
- 24 × 30 cm
- Spatial Resolution
- 6.0 Lp/mm
- X-ray Tube Anode
- Tungsten (W) Target with high thermal capacity
- Focal Spot Size
- 0.1 mm / 0.3 mm dual-focus
- Tube Voltage Range
- 20 kV to 40 kV in 1 kV increments
- Exposure Modes
- 2D Mode, 3D Tomo Mode, 2D+3D Combo Mode
- C-Arm Rotation
- ±180° iso-centric motorized rotation
- Breast Support Height
- 650 mm – 1350 mm motorized travel range
- Image Processing
- TRUVIEW image reconstruction, pseudo-color micro-calcification enhancement
- Connectivity
- Full DICOM 3.0 (Storage, Worklist, Print, Query/Retrieve)
- Net Weight
- 300 kg (Gantry)
- Certifications
- ISO 9001, ISO 13485, CE
Designed for daily confidence
Navigator Star Series Digital Mammography (3000A) combines accessible controls, optimized positioning, and high image quality to keep examinations moving smoothly.
- 3D Digital Breast Tomosynthesis (DBT)
- Flexible Combo Exposure Modes
- High-Resolution 24×30 cm FPD
- High-Speed Tungsten (W) Anode Tube
- Pseudo-Color Micro-Calcification Enhancement
- Streamlined Dual-Touchscreen Gantry
Product resources
Detailed brochures, configuration guidance, and regulatory documents are available from TMS Enterprise.
